Additional Attributes:
- GTIN: 00036584780373
- C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
- C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for On-Road Vehicles?: No
- C.A.R.B. Exemption Reason: N/A
- C.A.R.B. E.O. Number: N/A
- Camshaft Series: Magnum
- Usage: Street/Performance
- Cam Type: Hydraulic Roller
- Grind Number: 284HR
- Basic Operating RPM Range: 2,500-6,000
- Intake Duration at .050 Inch Lift: 224
- Exhaust Duration at .050 inch Lift: 224
- Advertised Intake Duration: 284
- Advertised Exhaust Duration: 284
- Lobe Separation: 110
- Intake Valve Lift: 0.533
- Exhaust Valve Lift: 0.533
- Lifters Included: No
- Valve Springs Required: Yes
- Assembly Lubricant Included: No
- Camshaft Gear Attachment: 1-Bolt
- Camshaft Material: Austempered Ductile Iron
- Lifter Type: Hydraulic Roller
- SK-Kit Upgrade: SK31-442-8
- K-Kit Upgrade: K31-442-8
- Engine Family: Ford 221, 260, 289, 302 c.i. 8 Cylinder (1963-1995)
- Cam and Lifter Kit Upgrade: CL31-442-8
- Amazon ASIN: B000P5B9QE
Extened Information:
- Emissions : Not Legal For C.A.R.B. - This part is not legal for sale or use in C.A.R.B. restricted areas
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 23.2 x 3 x 2.6 inches
PDF:
dddbebdc29809COMP Cams Camshaft FS 284Rf-HR10 - 31-442-8
