Additional Attributes:
- GTIN: 00036584780335
- Camshaft Series: Magnum
- Usage: Street/Strip
- Cam Type: Hydraulic Roller
- Grind Number: 304HR
- Basic Operating RPM Range: 3,000-6500
- Intake Duration at .050 Inch Lift: 244
- Exhaust Duration at .050 inch Lift: 244
- Advertised Intake Duration: 304
- Advertised Exhaust Duration: 304
- Lobe Separation: 110
- Intake Valve Lift: 0.576
- Exhaust Valve Lift: 0.576
- Lifters Included: No
- Valve Springs Required: Yes
- Assembly Lubricant Included: No
- Camshaft Gear Attachment: 1-Bolt
- Camshaft Material: Austempered Ductile Iron
- SK-Kit Upgrade: SK35-462-8
- Engine Family: Ford 351W 8 Cylinder (1969-1996)
- Lifter Type: Hydraulic Roller
- K-Kit Upgrade: K35-462-8
- Cam and Lifter Kit Upgrade: CL35-462-8
- Amazon ASIN: B001O09SC6
- C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
- C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for On-Road Vehicles?: No
- C.A.R.B. Exemption Reason: N/A
- C.A.R.B. E.O. Number: N/A
Extened Information:
- Life Cycle Status: Available To Order
- Emissions : Not in CA
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 23.3 x 2.83 x 2.67 inches
PDF:
dddbebdc29809COMP Cams Camshaft FW 304Rf-HR10 - 35-462-8
