Additional Attributes:
- GTIN: 00036584015703
- Camshaft Series: Xtreme Oval
- Usage: Strip
- Cam Type: Solid Flat Tappet
- Grind Number: 290XO-8
- Basic Operating RPM Range: 3400-7,200
- Intake Duration at .050 Inch Lift: 260
- Exhaust Duration at .050 inch Lift: 266
- Advertised Intake Duration: 290
- Advertised Exhaust Duration: 300
- Lobe Separation: 106
- Intake Valve Lift: 0.558
- Exhaust Valve Lift: 0.549
- Lifters Included: No
- Valve Springs Required: Yes
- Assembly Lubricant Included: Yes
- Camshaft Gear Attachment: 3-Bolt
- Camshaft Material: Cast Iron
- Engine Family: Chevrolet 262-400 c.i. 8 Cylinder (1958-1998)
- Lifter Type: Solid Flat Tappet
- Amazon ASIN: B000P593PI
- C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
- C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for On-Road Vehicles?: No
- C.A.R.B. Exemption Reason: N/A
- C.A.R.B. E.O. Number: N/A
Extened Information:
- Emissions : Not in CA
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 12 x 6.5 x 2.75 inches
PDF:
dddbebdc29809COMP Cams Camshaft CS 290Xo-6 - 12-658-5
