Additional Attributes:
- GTIN: 00036584059028
- Camshaft Series: Xtreme Energy
- Usage: Street/Performance
- Cam Type: Solid Roller
- Grind Number: XR274R-10
- Basic Operating RPM Range: 2,200-6,200
- Intake Duration at .050 Inch Lift: 236
- Exhaust Duration at .050 inch Lift: 242
- Advertised Intake Duration: 274
- Advertised Exhaust Duration: 280
- Lobe Separation: 110
- Intake Valve Lift: 0.65
- Exhaust Valve Lift: 0.657
- Lifters Included: No
- Valve Springs Required: Yes
- Assembly Lubricant Included: No
- Camshaft Gear Attachment: 1-Bolt
- Camshaft Material: Billet Steel
- Engine Family: Ford 429, 460 c.i. 8 Cylinder (1968-1995)
- Cam and Lifter Kit Upgrade: CL34-770-9
- K-Kit Upgrade: K34-770-9
- Lifter Type: Solid Roller
- Amazon ASIN: N/A
- C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
- C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for On-Road Vehicles?: No
- C.A.R.B. Exemption Reason: N/A
- C.A.R.B. E.O. Number: N/A
Extened Information:
- Emissions : Not in CA
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 14.8 x 2.75 x 2.67 inches
PDF:
dddbebdc29809COMP Cams Camshaft FF XR274 R-10 - 34-770-9
