Additional Attributes:
- GTIN: 00036584058960
- Camshaft Series: Xtreme Energy
- Usage: Street/Performance
- Cam Type: Solid Roller
- Grind Number: XR286R
- Basic Operating RPM Range: 3,000-7000
- Intake Duration at .050 Inch Lift: 248
- Exhaust Duration at .050 inch Lift: 254
- Advertised Intake Duration: 286
- Advertised Exhaust Duration: 292
- Lobe Separation: 110
- Intake Valve Lift: 0.614
- Exhaust Valve Lift: 0.621
- Lifters Included: No
- Valve Springs Required: Yes
- Assembly Lubricant Included: No
- Camshaft Gear Attachment: 1-Bolt
- Camshaft Material: Austempered Ductile Iron
- Engine Family: Ford 351W 8 Cylinder (1969-1996)
- Cam and Lifter Kit Upgrade: CL35-772-8
- K-Kit Upgrade: K35-772-8
- Lifter Type: Solid Roller
- Amazon ASIN: B000V9GBRQ
- C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
- C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
- C.A.R.B. Exempt for On-Road Vehicles?: No
- C.A.R.B. Exemption Reason: N/A
- C.A.R.B. E.O. Number: N/A
Extened Information:
- Life Cycle Status: Available To Order
- Emissions : Not in CA
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 24.1 x 2.9 x 2.7 inches
PDF:
dddbebdc29809COMP Cams Camshaft FW XR286 R-10 - 35-772-8
