4L80E/6X 3000-3200 Stall Triple-Disc Bolt-Together Converter

These high-stall torque converters feature woven-carbon friction and lock-up control technology which seamlessly applies the clutch. Each one features a removable billet front that allows access to the entire lock-up assembly, turbine, stator and bearings for servicing or re-stalling in the event of future vehicle modifications. The billet front is CNC-machined and made from pre-hardened steel. For added strength, TCI engineers included a pre-hardened billet turbine hub, lock-up piston and 50-spline clutch hub. The converters are fully furnace-brazed, computer-balanced and hand-assembled to precise tolerances.

Attributes:

• GTIN: 00788120146050
• Brand Name: TCI Automotive
• Center Hub Length: 2.78
• Center Hub Inside Diameter: 1.525
• Expected Stall Speed: 3000
• Engine Characteristics: High Horsepower
• Bolt Pattern (Diameter): 11.5
• Torque Converter Series: Bolt-Together Triple-Disc
• Housing Material: Steel
• Mounting Thread: M10x1.5
• Mounting Hardware Included?: Yes
• Disc Material: Carbon
• Number of Discs: 3
• Spline Quantity: 35
• Slotted Center Hub?: N/A
• Pilot Diameter: 1.702
• Outside Diameter: 12
• New or Remanufactured: New
• Grade Type: Performance - Billet Steel
• Lock Up Type: Yes
• Fluid Capacity: 2
• Color: HDT Gray
• Center Shaft Material: n/a
• Center Hub Outside Diameter: 2

Extended Information:

• Country of Origin: United States
• Emissions : Released
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 14 x 14 x 8 inches
• Weight: 44.35 lb
